Recommended for High pressure hydraulic oil lines. Meets SAE 100R16 and 100R17* dimension and performance. Meets SAE 100R2 and SAE 100R19* performance. Meets EN 853 2SN and EN 857 2SC performance.
*Applies only to size up to and including -12 for SAE 100R17 and -8 for SAE 100R19
Tube: Black,oil resistant, synthetic rubber (Nitrile, PVC)
Reinforcement: One braid of high-tensile steel wire.
Cover: Black, oil, abrasion and weather- resistant synthetic rubber (Nitrile) with colour coded layline.
Temperature Range: -40°F to +212°F (-40°C to +100°C)
SGX Standard: Available in black, Blue, Yellow and Red.
SGXFRAS Flame Retardant Anti Static: compliance to ISO6805
Flat plastic spiral wrap desiged to protect hose or bundle hose for appearance and safety.
Gates Nylon Sleeves perform a dual role:
They provide excellent abrasive resistance to protect individual hoses.
They can be used to bundle several hose assemblies together for maximum protection.
Downtime and maintenance costs are reduced.
Nylon Sleeves are unique because they form an extra protective layer against abrasive forces.
Construction: Thousands of tiny Nylon filaments, woven into the texturized yarn, "friz" providing a self-renewing shield that is extremely resistant to severe abrasion.
Note: Do not use Nylon Sleeve where ambient temperature exceeds 120°C.
